Sinusoidal sheet for wall cladding
Presentation
SUITABLE FOR:
industrial and civil cladding.
RECOMMENDED FOR:
internal cladding, external cladding.
STANDARD PRODUCTION:
aluminium
prepainted aluminium
prepainted steel
FRAMING COMPONENTS:
thanks to its wide range of accessories the system reduces considerably assembling work. Dry pose with no type of glue or cement.
![ond-all-33-sezione.webp](/static/313960984b060439a9412e84296dc36e/ond_all_33_sezione_0ec52e37ee.webp)
![ond-all-33-fissaggio.webp](/static/d3869a3f2d94a9d40e53e01bd0bfd75f/ond_all_33_fissaggio_9f897380e8.webp)
![ond-all-33-sormonto.webp](/static/f677e54d180869d7f789bf6c3208d9be/ond_all_33_sormonto_faf1deca71.webp)
Overlapping of a corrugation and a half
![ond-all-33-componenti.webp](/static/6619380cd3dbcc98cdf6fe44f87400b5/ond_all_33_componenti_3341490c4f.webp)
![struttura-facciate-staffa.webp](/static/326d14ede2595a24fe75f228ecbb7849/struttura_facciate_staffa_17b80d76ca.webp)
Supporting flask
![struttura-facciate-thermostop.webp](/static/2eb4010694ded39de12788f44bf30b5c/struttura_facciate_thermostop_e13f242372.webp)
Thermostop
![struttura-facciate-profilo-supporto.webp](/static/ad0c5bc1842b4949cb244e046334031a/struttura_facciate_profilo_supporto_c90cfe089c.webp)
Supporting profile
![struttura-facciate-bandella-dielettrica.webp](/static/aa9126245258521d0b24abf6fcc61cb4/struttura_facciate_bandella_dielettrica_603f13a95b.webp)
![struttura-facciate-profilo-partenza.webp](/static/dc1d432c6ef4ec2abcd52850108006e7/struttura_facciate_profilo_partenza_eea1851971.webp)
Prepainted aluminium
Standard colours
Prepainted steel
Standard colours
Smooth paintings
Other finishings
Processing
A = min 150 mm - B = min 50 mm or A = min 50 mm - B = min 150 mm | ||
Ri | Aluminium | Other materials |
1 m | max 3 m | max 3 m |
from 2 to 3 m | max 4 m | max 4 m |
from 3 to 4 m | max 5 m | max 5 m |
from 4 to 6 m | max 6 m | max 6 m |
from 6 to 7 m | max 8 m | max 8 m* |
*extra standard workings |
![ond-all-33-lavorazioni-curvatura-uniforme.webp](/static/d910dd922772ac21d252f91223e4b066/ond_all_33_lavorazioni_curvatura_uniforme_90a0987ae9.webp)
Symbology | ||
A | beginning part | min 50 max 150 mm |
B | final part | min 50 max 150 mm |
S | curved development | min 100 mm |
A+B+S | total development (aluminium) | max 4000 mm |
A+B+S | total development (other materials) | max 3000 m |
Ri | inner radius | min 280 mm |
P | imprint distance | min 25 mm |
a | deflection angle | min 1° max 4° |
![ond-all-33-lavorazioni-curvatura-parziale.webp](/static/6e1c6dac89c6bd3f2d84044d89747d8b/ond_all_33_lavorazioni_curvatura_parziale_df5a389262.webp)
Standard perforation: Ø 4mm, centre-to-centre 6mm, alternate 60°. Perforation of the laminate before cold forming enables to create darkening elements.
![ond-all-33-lavorazioni-foratura.webp](/static/5f33aa73572eac798f7a5107f53048c2/ond_all_33_lavorazioni_foratura_df2018aae1.webp)
